Mxology Billet Race Piston 2618 - Triumph TF250X

Mxology Billet Race Piston 2618 - Triumph TF250X

Regular price $649.99 USD
Regular price Sale price $649.99 USD
Sale Sold out
Shipping calculated at checkout.
Select your bike to check fit

Shipping quoted by the parts desk

We do not put a shipping price on this one automatically — it is quoted by hand so you are charged what it actually costs. Tell us where it is going and we will come back with a real figure, or collect it in Brea at no charge.

Request Shipping Quote
Call the Parts Department · (714) 256-6700

Collecting in Brea? Say so on the request and there is no shipping charge at all.

30-day returns on unused items, tags on.
If our fitment data or advice was wrong, we make the shipping correction right.

In-Store: stocked at our Brea shop for pickup, or ships nationwide.

Not sure it fits? Ask the Parts Desk →

The billet version, cut in the UK from high grade 2618 bar instead of forged. Same alloy reasoning as the forged piston, with skirt geometry and a ring package developed specifically for the British 250F engine. This is the premium option of the two.

Before you order: 15.4:1 is a race compression ratio. Run fuel to suit it.

Specification

  • Machined from high grade 2618 aluminium billet, full underside machining
  • Optimised skirt geometry
  • 15.4:1 compression ratio with the OEM head gasket
  • 0.8mm low tension compression ring, positive twist, barrel faced, PVD coated
  • 1.5mm steel three piece oil control ring
  • DLC coated high performance steel wrist pin
  • Round wire spring steel retaining clips, dressed and rumbled ends

Fits: 2024-26 Triumph TF250X
