Main Frame Assembly
Triumph TXP-20 · 2024 · Chassis & Suspension · 20 parts
Open this diagram in the interactive viewer → Click any callout on the drawing to jump to the part.
Every part on this diagram
1
12
T2075966
Protect Decal, Batt Tray, LRG
Qty 2
Backordered at Triumph · we’ll confirm the ship date after you order
$2.82
On backorder
19
TOS30069
Bolt,M6X14Mm,Cap+Wash,10.9,Blk
Qty 4
Backordered at Triumph · we’ll confirm the ship date after you order
$1.99
On backorder
22
T2075654
Decal, Tri TXP-20, Fr Splash
Qty 1
Backordered at Triumph · we’ll confirm the ship date after you order
$7.15
On backorder
Diagram and part data from Triumph’s own parts catalogue. Prices and availability are a dated snapshot, not a reservation. Fitment is Triumph’s data — send us the last six of your VIN if you want it checked before you order.
