Brake Assemblies

Triumph TXP-12 · 2026 · Accessories · 13 parts

Exploded parts diagram — Brake Assemblies, Triumph TXP-12

Open this diagram in the interactive viewer → Click any callout on the drawing to jump to the part.

Every part on this diagram

1
T2022885
Brake Adaptor, IS-160PM, R
Qty 1
Backordered at Triumph · we’ll confirm the ship date after you order
$5.35
On backorder
2
T2022971
Rhs Brk Cable Lever, Blk
Qty 1
$5.66
Available
3
T2022972
Lhs Brk Cable Lever, Blk
Qty 1
$5.66
Available
4
T2022973
Brk Cable Disc Caliper, Blk
Qty 2
$24.23
Available
5
T2022974
Brk Cable End Crimp
Qty 2
Backordered at Triumph · we’ll confirm the ship date after you order
$1.99
On backorder
6
T2022977
Front Cable Assy
Qty 1
$1.99
Available
7
T2022978
Rear Brk Cable Assy
Qty 1
$2.32
Available
8
T2022989
Bolt, Caliper, M6X17Mm, Blk
Qty 2
Backordered at Triumph · we’ll confirm the ship date after you order
$1.99
On backorder
9
T2022995
Bolt, Caliper, M6X23Mm, Blk
Qty 4
Backordered at Triumph · we’ll confirm the ship date after you order
$1.99
On backorder
10
T2022996
Lower Caliper Washer
Qty 4
Not Shown.
$1.99
Available
11
T2022997
Upper Caliper Washer
Qty 4
Not Shown.
$1.99
Available
12
T3700015
Cable Tie, 185.7 Long
Qty 1
$1.99
Available
13
T2029824
Brake Pads, Pair
Qty 1
Backordered at Triumph · no date yet
$27.91
On backorder Ask the parts desk

Diagram and part data from Triumph’s own parts catalogue. Prices and availability are a dated snapshot, not a reservation. Fitment is Triumph’s data — send us the last six of your VIN if you want it checked before you order.
