Battery

Triumph OSET TXP-24 · 2023 · Accessories · 6 parts

Exploded parts diagram — Battery, Triumph OSET TXP-24

Open this diagram in the interactive viewer → Click any callout on the drawing to jump to the part.

Every part on this diagram

1
T5300014
Battery, Li-Ion, 50V, 14S7P
Qty 1
$1036.46
Available
4
T5300015
Battery Strap Assy, Frnt, 28AH
Qty 1
$11.83
Available
5
TOS30021
Bolt, M5X10Mm, Flgd, 10.9, Blk
Qty 6
$1.99
Available
6
T5300016
Battery Strap Assy, Rear
Qty 1
$5.00
Available
7
T5300017
Battery Pad,Rubber,Black
Qty 2
$7.91
Available
8
TOS30044
Bolt, M5X12Mm, Butt, 10.9, Blk
Qty 4
$1.99
Available

Diagram and part data from Triumph’s own parts catalogue. Prices and availability are a dated snapshot, not a reservation. Fitment is Triumph’s data — send us the last six of your VIN if you want it checked before you order.
