Side panels

Triumph OSET MX-10 · 2024 · Bodywork · 10 parts

Exploded parts diagram — Side panels, Triumph OSET MX-10

Open this diagram in the interactive viewer → Click any callout on the drawing to jump to the part.

Every part on this diagram

1
TPLA112114
Grips, OSET, Pair, Thin, Grey
Qty 2
$14.37
Available
2
TPLA071328
Tank Cover, L130, Mldg, Blk
Qty 1
$15.62
Available
3
TPLA031334
No. Board, MX10, Rr, Mldg, Blk
Qty 1
$31.25
Available
4
TPLA051332
Infill Panels, H389, Mldg, Blk
Qty 2
$61.85
Available
5
TPLA061384
Splash Guard Fixing Plate, Blk
Qty 1
$7.18
Available
6
TPLA061331
S Guard, Rr, Rubber, Blk
Qty 1
$19.37
Available
7
TPLA101361
Fork Guards, USD 24, White
Qty 1
$25.00
Available
8
TCHS122537
Headset, Star Nut, STL, Blk
Qty 1
$6.25
Available
9
TPLA031330
No. Board, MX10, Flat, White
Qty 1
$15.62
Available
10
TPLA061342
S Guard, Fr, MX-10, Blk
Qty 1
Backordered at Triumph · we’ll confirm the ship date after you order
$15.62
On backorder

Diagram and part data from Triumph’s own parts catalogue. Prices and availability are a dated snapshot, not a reservation. Fitment is Triumph’s data — send us the last six of your VIN if you want it checked before you order.
